Clap Snare Eurorack Module


Need some snap and crack added to your drum rack?

Don't want a lot of complicated controls?

Then this module is for you.

The module contains two independent percussion sound generating circuits.

Circuits are turned to produce sounds similar to a clap sound and snare drum.

Based on a self excited Bridged-T Filter, with digital white noise.

Takes 5 millisecond trigger pulse and outputs a drum sound.

Two control knobs D and F

D controls the duration of the release of the generated sound, adjustable from a quick hit to a long roll off.

F controls the frequency of the percussion sound, from deep and low to snappy and high.

What's in the Bag?

Complete 100% tested module

12 inch 10 pin unpolarized power cable

Two M2.5 screws

Two M3 screws

2 black nylon washers

Input impedance 100K ohm

Output impedance less then 1K ohm

Compatible with both 5V and 12V trigger pulses with an output impedance of 1K ohm.

Current consumption: +12V 20mA, -12V 15mA

compatible with +-15V systems.

<!-- @page { margin: 0.79in } p { margin-bottom: 0.1in; line-height: 120% } -->

Module is polarity protected.
